Manual Feed Shuttle

Manual Feed Shuttle
Forming
  • Food Containers
  • Wrapping/Packaging Materials
Cutting
  • Food Containers

Product Image

  • Manual Feed Shuttle Exterior image image (No background color)

Main Specifications

  • Rice Bowl-style Food Containers
  • Tray Food Containers

Product Video

Main Specifications

Cutting Area
1200mm (Width)×800mm (Feed)
Cutting Force
75TON
Platen Vertical Stroke
20 – 150mm
Main Motor
11kw
Tuning System
Mechanical Type

Features

  • Smooth separation of product from scrap and collection of product
  • AC servo motor used for movement with vacuum BOX for high-speed and high-precision
  • Thomson die cut unit and mating die can be used for cutting
  • Cutting machine uses high-speed type of vertical cutting
  • Simplified setup process

Options

  • Static Elimination Equipment
  • Electric Parallel Blocks
  • Mat Transferring

Inquiries

Since we can also make appointments for meetings upon request, please feel free to contact us.
